Qtenboard Self Service Kiosk
Two World-Class Manufacturing Bases in Shenzhen & Guangzhou — To ensure stable supply, high consistency, and long-term cooperation for global brands, Qtenboard operates two large-scale factories with fully controlled production processes for self-service ticketing kiosk and self service kiosk solutions.
The following technical parameters are based on a 32-inch QM-L3226DC self-service ticketing kiosk model. If you need technical parameters for other sizes, please contact Qtenboard.
| Display parameter | |
| Brand | Qtenboard |
| Model | QM-L3226DC |
| Screen Size | 32inch |
| Resolution | 1920*1080, 2K；3840*2160, 4K. |
| Angle of view | 178° |
| Contrast ratio | 3000:1 |
| Display size | 392.9×699.5mm（H×V） |
| Display rate | 16:9 / 9:16 |
| Back light | LED |
| Brightness | ≥300 / 400 / 500 cd/㎡ |
| Refresh rate | 60 / 120 HZ |
| Color | 16.7M(8-bit) / 1.07B (10-bit) |
| System configuration | |
| Operation system | Windows 10 / 11 |
| Version | Intel i3 / i5 / i7 |
| CPU | 4 / 6 / 8 / 10 / 11 / 12 / 13 / 14 th |
| RAM | 8 / 16 / 32 GB |
| Storage memory | 128 / 256G / 512G |
| interface | DC*1 USB*4 RJ45*1 Audio*1 VGA*1 HDMI*1 |
| Network | 1pc,1000M |
| WIFI & Bluetooth | Built in WIFI（2.4G/5G）& BT 4.2 / 5.0 / 5.4 |
| 3G/4G | Optional |
| Basic Function | |
| Decoding Capability | Supports 2/4K video and picture decoding and playback |
| Software application | Support to install the third-party software |
| Language | English etc language |
| Boot Animation | Support to customize |
| Infrared remote control | Operate system by remote control |
| Audio function | Support left/right channel output,built-in double 8Ω power amplifier |
| Power-on/off | Remote control/timing/network wake-up/self-start |
| System authorization | Allow root permission and customize software development |
| Mouse mode | support wired/wireless mouse or use keyboard |
| System update | Support local and remote upgrade |
| More functions | follow instruction manual/video or contact supplier |
| Machine parameter | |
| Color | Black / White / Others |
| Frame material | Aluminum(oxidized wire drawing) |
| Body Material | Metal cold rolled steel plate (metal coating) |
| Surface material | 3mm tempered glass(physical) |
| Product size | 511.7*1763.5*50mm(For reference only) |
| Packing size | 511.7*450*30mm(For reference only) |
| Packing material | Neutral carton / Wooden frame / Wooden box |
| Net/gross weight | 30KG/35KG (For reference only) |
| Install ways | Mount-on wall/Embedding/Hang/Bracket |
| Electrical features | |
| Scenarios | indoor |
| Rated Voltage | AC110-220V |
| Stand by power | ≦1W |
| Rated power | ≦85W |
| Suitable Environment | temperature‐0℃~55℃/humidity 10%RH~90%RH |
| Storage Environment | temperature‐5℃~60℃/humidity 10%RH~90%RH |
Ideal for self-ordering in restaurants to speed up service and reduce waiting lines — a proven self-service ticketing kiosk and self service kiosk application.
Ideal for metro and bus stations for easy ticket purchasing and balance top-ups using a self-service ticketing kiosk or self-service ticketing kiosk for airports and stations.
Suitable for government halls to simplify public services and reduce manual processing with self-service ticketing kiosk and ticketing kiosk solutions.
| Feature | Description |
|---|---|
| Brand Logo & Boot Animation | Personalize your self-service ticketing kiosk with custom logos and startup animations for full brand identity. |
| UI/OS Deep Customization | Tailor system interface, themes, and functionality of your self-service ticketing kiosk to match your brand’s unique requirements. |
| Chassis & Mold Modification | Modify device enclosures or design new molds for differentiated self-service ticketing kiosk appearance. |
| Packaging Design | Custom packaging for self-service ticketing kiosk to suit your branding and global shipping needs. |
| SN Tracking & Batch Production | Each self-service ticketing kiosk unit tracked with a unique serial number to ensure quality and manage after-sales efficiently. |
| White Label Services | Offer self-service ticketing kiosk products ready to market under your own brand name. |
| CKD/SKD Supply Capability | Flexible shipment options for self-service ticketing kiosk: complete, semi-knocked down, or fully assembled units. |
| Software Development & SDK/API Support | Integrate third-party applications or develop proprietary software for self-service ticketing kiosk to meet specific project needs. |
Factory Entrance — Modern and spacious facility designed for high-efficiency self-service ticketing kiosk production.
Production Line — Fully automated assembly lines for consistent self-service ticketing kiosk quality output.
Quality Control — Rigorous testing ensures reliable self-service ticketing kiosk for global clients.
Warehouse & Logistics — Organized storage and efficient shipping for worldwide self-service ticketing kiosk distribution.
United States — Quick-Service Restaurants — Self-ordering kiosks reduce wait times and improve order accuracy, including self-service ticketing kiosk deployments.
Spain — Shopping Malls — Interactive directories improve navigation and visitor engagement with self-service ticketing kiosk and ticketing kiosk.
Belgium — Universities — Campus kiosks support student services, schedules, and maps via self-service ticketing kiosk.
United Kingdom — Transportation Hubs — Ticketing kiosks provide fast and convenient ticket purchases with self-service ticketing kiosk technology.
Italy — Museums & Tourist Sites — Information kiosks offer multilingual guides and ticketing services, including smart self-service kiosk for museum solutions.
Norway — Public Libraries — Self-service terminals simplify book borrowing and returns with self-service ticketing kiosk and ticketing kiosk.
Germany — Trade Shows — Fast check-in kiosks accelerate attendee registration at large events using self-service ticketing kiosk.
Netherlands — Corporate Headquarters — Visitor kiosks automate check-in and enhance lobby security with self-service ticketing kiosk.
Ireland — Hotels — Check-in kiosks help guests skip queues and access rooms faster, leveraging self-service ticketing kiosk and automated ticketing kiosks for smart parking.
Qtenboard provides a complete pre-sales and after-sales service system, ensuring stable long-term cooperation and smooth project delivery for international brands and distributors of self-service ticketing kiosk and self service kiosk.
Ready to upgrade your self-service ticketing kiosk project? Get in touch with our team for customized solutions, pricing, and samples.
Trusted by global brands for self-service ticketing kiosk, self service kiosk, and ticketing kiosk solutions.
